Assembly of header transmission shaft 2m for Zoomlion Harvester

Spare Parts Name: Assembly of header transmission shaft 2 for Zoomlion Harvester
Weight(kg):
Application: use for Zoomlion Combine Harvester
Material:IRON/STEEL
Features:

  • High hardness and long service life
  • Durable cast steel,wear resistance,Anti-corrosion
  • Standard parts,conforms to the Original standard.

  • Product Details
  • Inquiry

Assembly of header transmission shaft 2m  for Zoomlion Harvester

REF.NoPART No.PRODUCT CODEPART NAMEQ’TY
1GB/T5783-M10×161040005561Bolt1
2GB/T93-101040300067Spring washer1
34LZS2-08.09.01-01017406011ZA000080Shaft end ring1
4ZT40ZG.1.1C.3-05a017405011ZA100073Belt pulley1
5ZT40ZG.1.1.3-04017405011ZA100072Transmission shaft spacer1
6GB/T1096-A8×401040600382Flat key1


7



GB/T7810-UCP206

1050200976Insert bearing with housing UCP206

2

8GB/T5783-M12×451040000169Bolt4
9GB/T93-121040300054Spring washer4
10GB/T97.1-121040300607Flat washer4
11ZT40ZG(X).1.1C.3-02b017405011ZA100149Header transmission shaft1
12ZT40ZG(X).1.1C.3-06b017405011ZA100074Chain wheel1
13GB/T6191-M8×101040100260Bolt2
14ZT40ZG.1.1C.3.1c017405011ZA100075swing ring eccentric shaft1
15GB/T276-6208-RZ1050201688Bearing2
16ZT40ZG.1.1.3-01017405011ZA100069Rocker arm bracket1
17GB/T893.1-801040300125Retaining ring for bores1
18GB/T894.1-401040300096Retaining ring for shaft1
19ZT40ZG(X).1.1C.3-03a017405011ZA100150Sheath1
20GB/T1243-10A-831031002171Chain-83 sections1

Assembly of header transmission shaft 2 for Zoomlion Harvester
